Paccar MX-13 Programming Guide

PEC017
5/3/2018 Page 6 of 105
MX-11 Standard Feature
Maximum Horsepower
Maximum Torque
385 HP @ 1600 RPM
1,450 lbf-ft @ 1000 RPM
MX-11 Feature Options
Maximum Horsepower
Maximum Torque
335 HP @ 1,600 RPM
1,150 lbf-ft @ 900 RPM
355 HP @ 1,600 RPM
1,250 lbf-ft @ 900 RPM
REFUSE 355 HP @ 1,600 RPM
1,250 lbf-ft @ 900 RPM
375 HP @ 1,600 RPM
1,350 lbf-ft @ 900 RPM
400 HP @ 1,600 RPM
1,450 lbf-ft @ 900 RPM
REFUSE 400 HP @ 1,600 RPM
1,450 lbf-ft @ 900 RPM
415 HP @ 1,600 RPM
1,550 lbf-ft @ 900 RPM
MT 430 HP @ 1,600 RPM
1,450 - 1,650 lbf-ft @ 900 RPM
430 HP @ 1,600 RPM
1,650 lbf-ft @ 900 RPM

Paccar MX-13 Specifications

General

Engine Type	Diesel
Displacement	12.9 liters
Configuration	Inline 6-cylinder
Horsepower Range	405-510 hp
Torque Range	1450-1850 lb-ft
Bore	5.12 inches
Fuel System	Common Rail
Emissions	GHG17 compliant
Oil Capacity	42 quarts
Coolant Capacity	56 liters
Aftertreatment	Diesel Particulate Filter (DPF), Selective Catalytic Reduction (SCR)
Stroke	6.42 inches (163 mm)
