Paccar MX-13 - In-Cab Control Configuration, Limits, and Set Points

PEC017
5/3/2018 Page 61 of 105
N081
Page 56
Min
Default
Max
Units
PTO Mode Maximum Engine Speed
Rate of Change
50
75
200
RPM/SEC
* To Enable, Enable PTO Mode Engine Ramp Rate Limiter (N109) must be ON
N086
Page 56
Min
Default
Max
Units
Maximum Engine Speed using
Switch Inputs
N106
2000
2000
RPM
* Must be greater than or equal to PTO Mode Minimum Engine Speed (N106)
* For Remote applications, should be set to Customer’s requested Maximum
Engine Speed
N106
Page 55
Min
Default
Max
Units
PTO Mode Minimum Engine Speed
N052
650
2000
RPM
* Must be greater than or equal to Engine Idle Speed (N052)
* May not be greater than 800 RPM if Require Parking Brake for PTO Mode
(N079) and Neutral Required for PTO Mode (N089) are disabled
* May not be greater than 950 RPM if Require Parking Brake for PTO Mode
(N079) and Neutral Required for PTO Mode (N089) are disabled, and Disable PTO
Mode w/ Brake Depressed(N106) is enabled.
N109
Page 56
Min
Default
Max
Units
Enable PTO Mode Engine Ramp
Rate Limiter
OFF (0)
OFF (0)
ON (1)
ON/OFF
In-Cab Control Configuration, Limits, and Set Points
N082
Page 56
Min
Default
Max
Units
Engine Speed Decrease w/
Res/Decel (In-Cab)
10
50
1000
RPM
N083
Page 56
Min
Default
Max
Units
Engine Speed Increase w/ Set/Accel
(In-Cab)
10
50
1000
RPM
N084
Page 56
Min
Default
Max
Units
Engine Speed Ramp-down
w/Res/Decel (In-Cab)
10
250
1000
RPM/SEC
