PEC017
5/3/2018 Page 74 of 105
16.0 Engine Recorder
Overview
The Engine Recorder records three types of engine-sensor and calculated-output
data over the life of the vehicle, between reset and defined durations. Each type of
data record is stored independently and depending on the type, multiple records
might be stored. The records for the three recorders are retrievable with the DAVIE
service tool.
Standard Feature
Combined Trip/Chart Recorder
Snapshot Recorder
Faststop Recorder
The Combined Trip/Chart Recorder allows the engine to store data over the life of
the vehicle as well as to store data between resets. When the trip reset is triggered,
the record is discarded and new data is collected.
The Snapshot Recorder allows the driver to trigger a recording event. Details on
triggering the Snapshot Recorder are available in Engine Rapido. The Snapshot
Recorder will record data 10 seconds before and 5 seconds after the trigger. Three
Snapshot Recorder events will be stored.
Faststop Recorder allows the engine to trigger a recording event when vehicle
deceleration is greater than Faststop Recorder Threshold (N064). The Faststop
Recorder will record data 5 seconds before and 5 seconds after the trigger. Three
Faststop Recorder events will be stored.
Feature Options
Without Faststop Recorder
The Faststop recorder is enabled by default. Customers may disable the Faststop
recorder at the time of production by selecting the appropriate sales code.
Orderable Feature Options & Sales Codes
