PEC017

5/3/2018 Page 77 of 105

N247

Page 76

Min

Default

Max

Units

Driver Shift Aid Lowest Active Gear

1

1

4

GEAR #

N248

Page 76

Min

Default

Max

Units

Driver Shift Aid Highest Active Gear

5

TOP

GEAR

TOP

GEAR

GEAR #
