BRAKE SAFETY AND EMERGENCY PART 7: STARTING & OPERATING THE VEHICLE
– 122 – Y53-6032 (05/10)
To release spring brakes manually
1. Remove the cap from the spring chamber.
2. Remove the release stud assembly from the side
pocket; remove the release nut and washer from the
release stud.
:
02936A
02936B
Y53-6032.book Page 122 Monday, May 24, 2010 3:37 PM
