Set-Up
Tip & Tool Stand
If you have purchased a system with a handpiece, set up the Tip & Tool Stand in the
following manner. Set up any other SensaTemp handpiece, use the instructions
enclosed with the handpiece and associated Tip & Tool Stand.
1. Attach the stand to either side of the power source, in the following manner.
a) Insert the 2 large hex head
Mounting Screws (head first) into
the lower "T" slot on the side of
the power source case as shown.
b) Place the Tip & Tool Stand in
position beside the power source.
Insert ends of the 2 Mounting
Screws into the 2 Tip & Tool
Stand mounting holes shown.
c) Install a Thumb Nut onto the end
of each Mounting Screw.
Tighten Thumb Nuts to secure
the stand in position.
2. Place handpiece into Tip & Tool Stand.
