Table 6. Spare Parts
Spare Parts
Table 5. Packing List
Packing List
Item # Description Part Number
1
Fuse,(F1), 1.25 Amp Time Lag, 115 Volt Systems 1159-0251
0.63 Amp Time Lag, 230 Volt Systems 1159-0252
2
Power Cord 115 Volt Systems 1332-0094
230 Volt Systems 1332-0095
3 Power Switch 1157-0081
4 Bumpon (rubber foot) 1274-0021
5 PCB Assembly 6020-0124-P1
6 Motor Pump Assembly 1336-0037-P1
Accessories & Spare Parts (partial list, complete listing in catalogue)
7 Tip & Temperature Selection System Booklet 5050-0251
8 SX-80 Sodr-X-Tractor Handpiece 6010-0106-P1
9 SX-80 Heater Assembly 6010-0107-P1
10 PS-80 Handpiece 6025-0014-P1
11 DTP-80 Dual ThermoPik Handpiece 7029-0001-P1
12 TT-65 ThermoTweez Handpiece 7025-0001-P1
13 TP-65 ThermoPik Handpiece 7024-0001-P1
14 TJ-70 ThermoJet Handpiece 7023-0002-P1
Quantity Supplied
This is a packing list of the items shipped with the system and is current at
the time of publication of this manual.
ST 115-SX80
Systems
ST 115P-SX80
Systems
Item # Description Part # ST 115 ST 115E ST 115 ST 115E
1 ST 115 System Power Source - - - - - 1 1 1 1
2 SX-80 Handpiece, (48 Watts) 6010–0106 1 1 1 1
3 Power Supply Cord, 115 VAC 1332-0094 1 0 1 0
4 Power Supply Cord, 230 VAC 1332-0093 0 1 0 1
5 Tip & Tool Stand Kit 6019-0060-P1 1 1 0 0
6 SX-80 Accessory Kit - - - - - 1 1 1 1
7 Portability Kit 6018-0109-P1 0 0 1 1
8 Air Fitting Adaptor 1259-0081 0 1 0 1
9 Operation & Maintenance Manual 5050-0460 1 1 1 1
10 Tip Tool 1100-0206 1 1 1 1
