Pacmac 2015 - NIP ROLLER ADJUSTMENT

2015OPERATIONSMANUAL

32

HOW TO ADJUST NIP ROLLER
1. LOCATE THE 2 TENSIONING SPRINGS ON THE LEFT AND RIGHT
SIDE OF THE NIP ROLLER.
2. THE SPRINGS CAN BE LOOSENED OR TIGHTENED VIA THE 1/2”
NUTS ON THE TENSIONING EYE BOLTS.
3. SPRINGS SHOULD MAINTAIN AN 1/8” GAP BETWEEN COILS WHEN
THE NIP ROLLER IS CLOSED.
TENSION SPRINGS
ADJUSTMENT NUT
EYE BOLT
