PACOM PDR420 - Specifications

User’s Manual
22 V1.0
SPECIFICATIONS
VIDEO
Signal Format NTSC or PAL (auto detect)
Video Input Composite: 4 looping inputs, 1 Vp-p, auto-terminating, 75 Ohms
Monitor Outputs Composite: One (BNC), 1 Vp-p, 75 Ohms
Video Resolution 720x480 (NTSC), 720x576 (PAL)
Playback/Record Speed
(images per second)
30ips (NTSC), 25ips (PAL)
INPUTS/OUTPUTS
Alarm Input 4 TTL, NC/NO programmable, 4.3V threshold
Alarm Output 1 relay out, terminal block, NC & NO, 0.5A @ 125VAC, 1A @ 30VDC
Internal Buzzer 80dB at 10cm
Network Connectivity 10/100 Base Ethernet
CONNECTORS
Video Input Composite: 4 BNC
Video Loop Composite: 4 BNC
Monitor Output Composite: 1 BNC
Alarms Terminal block
Ethernet Port RJ-45
RS-485 Serial Port 2 connector terminal block
USB Port 1 on front panel (2.0)
STORAGE
Primary Storage EIDE hard disk drive
GENERAL
Dimensions (W x H x D) 13.38 x 1.83 x 2.38 (340.0mm x 46.5mm x 314.5mm)
Unit Weight 6.67 lbs. (3.03kg)
Shipping Weight 9.88 lbs. (4.49kg)
Shipping Dimensions
(W x H x D)
17.32 x 6.22 x 16.14 (440mm x 158mm x 410mm)
Operating Temperature 41°F to 104°F (5°C to 40°C)
Operating Humidity 0% to 90%
Power 100-240 VAC, 0.8-0.4A, 50/60Hz
Approval FCC, CE, CB, UL
Specifications are subject to change without notice.
