84
Folding In and Retracting the Platform
Protect your hands with gloves.
Grasp the platform edge with both hands to fold back the
platform.
Pull the folding part of the platform with both hands to fold it
back.
Close the platform interlock (if present).
Swivel the platform up to the roller at the support tube.
Turn the rotary switches (27) and (29) simultaneously up-
ward and hold them in this position until the platform has
reached the retraction height.
Turn the rotary switch (30) upward and hold it in this posi-
tion until the platform is completely retracted. Observe that
the platform can be retracted without obstruction.
Turn the rotary switches (27) and (29) simultaneously upward
and hold them in this position until the platform has reached the
vibration safeguard.
Betriebsanleitung_Hubladebuehnen_EN.book Seite 84 Donnerstag, 15. August 2019 4:04 16
