PTV 35/44/55/66 Installation Manual
Rev. 1.1 38
2. Installing the Liftgate: The installation process is the same as the Weld-On version of the liftgate. Follow
the Preparation, Mounting, and Welding procedures from Sections 10 & 11.
3. Finalizing Installation: To finalize this method of installation, both column wraps on the liftgate must be
welded to the vehicle in the location shown below.
Right
Bolt-On
Column
Wrap
Vehicle
Corner
Post
1/4"
3"
2X
Optional:
For moderate to heavy use, it is
recommended to weld the column
wraps to the vehicle.
End of
Vehicle
Body
3"
1/4"
2X
To Next Page
