PTV 35/44/55/66 Installation Manual
Rev. 1.1 27
11 Liftgate Mounting
This manual features installation procedures for “Weld-On PTV” and “Bolt-On PTV” liftgate models.
Before continuing with the installation, identify what PTV model is to be installed.
11.1 Mounting the Liftgate (Standard Installation)
Before positioning the liftgate; consider when measuring and centering the liftgate that the truck or
trailer may NOT be perpendicular to the ground. Special care must be taken to ensure that the liftgate
is perpendicular to the ground before welding.
Steps:
1. Level Vehicle: The vehicle must be on level and even ground. Uneven ground will give misleading
measurements and can cause body twist or raking.
