A = Bedheight:.....................................________ Loaded Bedheight:.....................................________
B = Top of floor to bottom of frame:.............................................................................................________
C = Rear sill height:.......................................................................................................................________
D = Spring hanger to end of body (if applicable):......................................................................________
E = Air bag suspension to end of body (if applicable):..............................................................________
F = Tire to end of vehicle body:....................................................................................................________
G = Gas tank to end of body (if applicable):................................................................................________
H = Fuel filler hole to end of body (if applicable):......................................................................________
I = Bottom of frame to bottom of gas tank (if applicable):........................................................________
J = Top of floor to bottom of sliding walk ramp (if applicable):.................................................________
K = Frame Width: Width of chassis frame:..................................................................................________
L = Frame Height: Height of chassis frame:................................................................................________
Truck Information
Truck Dimensions
Type of Body
(check applicable)
Van
Flatbed
Reefer
Other (specify)____________
Type of Rear Door
(check applicable)
Flip-Up
Roll-Up
Swing
Other (specify)________________
Truck Specifications:
Manufacturer:
(ex. Hino)
GVWR:
(ex. 68,000 lbs)
Length:
(ex. 53ft)
Width:
(96", 102")
Truck Chassis Dimension Sheet
Liftgates Information:
Model
Capacity
Platform Size
Platform Material
90-9813-003_b
Notes:
Side View of Truck
Rear View of Truck
Walk Ramp (if applicable)
A
B
C
D
E
F
G
J
H
I
K
L
Customer Information
Quote#/SO#:____________________________________________________
Company:______________________________________________________
Phone:_________________________________________________________
Email: _________________________@______________________________
