PTV 35/44/55/66 Installation Manual
Rev. 1.1 24
9.4 Support Body
Side supports can be used to strengthen the body.
Steps:
1. Add body supports (If necessary): If extra support is required, add support bars as shown below.
Flatbed installations may use a similar arrangement with 3/16” x 4” x 4” min. rectangular tubing for corner
posts and 3” channels for support bars.
72"
Approximately
60"
Support Bar
1/4"x3 Min. Flat Bar
1/4"x3" weld each end
Sub-plate for aluminum side rails
1/4"x4" min bolted on either side
of the body cross members.
