T5 Flare Gas Transducer Installation Guide 35
Chapter 3. Installing the Transducer Assemblies
3.2.2 Mounting the Insertion Mechanism (cont.)
5. Visually inspect the mechanism. Make sure the transducer is recessed in the packing gland. Again, make sure
the top compression fitting is secure and hand tight.
Bias 90 Assembly
with 90° Head
Transducer
Recessed in
Packing Gland
Tilted Diameter Assembly
with 180° Head
Transducer
Recessed in
Packing Gland
To Next Page
