Chapter 3. Installing the Transducer Assemblies
34 T5 Flare Gas Transducer Installation Guide
3.2.2 Mounting the Insertion Mechanism (cont.)
4. Retract the barrel from the packing gland so that the transducer head is recessed in the packing gland. You will
hear the stop ring click into place when the transducer is fully recessed.
Compression Fitting
(hand tight)
