TRANSITION
TIME
DISPLAY
Used
to
display
the
transition
time
in
frame
units
during
the
Wipe,
Dissolve
or
DSK
mode.
Refer
to
page
41.
PATTERN
NUMBER
DISPALY
Used
to
display
the
number
of
patterns
during
the
Wipe
or
Dissolve
mode.
Refer
to
page
41.
@
AUTO
key/lamp
Used
to
set
the
edit
point
entry
mode
when
the
AG-SW800
audio/video
switcher
is
used
and
the
video
is
manually
switched
using
the
Take
key.
Refer
to
page
51.
@
TRAN
key/lamp
Used
to
set
the
transition
time.
Refer
to
page
41.
©
DIS
key/lamp
Used
to
switch
the
screen
using
the
dissolve
effect.
After
pressing
this
key,
you
can
do
different
kinds
of
dissolve
effects
by
specifying
the
number.
The
P
IN/OUT
point
will
give
a
fade
in/out
effect.
.
Refer
to
page
46.
©
WIPE
key/lamp
Used
to
switch
the
screen
using
the
wipe
effect.
After
pressing
this
key,
you
can
use
different
wipe
patterns
by
entering
the
pattern
numbers.
Refer
to
page
47.
@
KEY
key/lamp
Used
to
set
the
down
stream
keyer
effect.
Refer
to
page
48.
@
TAKE
key
If
pressed
when
the
sync-roll
is
executed,
the
switcher
will
switch
the
A
roil
to
the
B
roll.
Refer
to
page
51.
@
Effect
point
select
key
Used
to
select
the
effect
points.
P
IN:
Press
this
key
to
record
the
fade-in
effect.
A/B:
Press
this
key
to
record
effect
at
the
A/B
point.
P
OUT:
Press
this
key
to
record
the
fade-out
effect.
@
AUDIO
key/lamp
Used
to
record
the
audio
effect.
Release
the
key
to
record
the
normal
video
effect.
Refer
to
page
50.
LOAD
key/lamp
If
pressed,
the
lamp
will
light
up
and
the
edit
data
will
be
entered
from
the
computer
through
the
25-pin
DATA
IN/OUT
terminal.
Refer
to
page
65.
SAVE
key/lamp
If
pressed,
the
lamp
will
light
up
and
the
edit
data
will
be
Output
to
the
computer
through
the
25-pin
DATA
IN/OUT
terminal.
Refer
to
page
65.
@
10
key
Numeric
Pad
Used
to
enter
the
desired
numbers
of
the
edit
IN/OUT
points,
and
event
after
selecting
the
registering
mode.
@
~
key
Used
to
set
or
check
the
range
for
automatic
edits.
Press
this
key
to
set
or
check
the
range
of
the
automatic
editing.
(See
pages
35,
60.)
@
+,
key
Used
to
change
the
edit
point
by
addition
and
subtraction.
@
C
(Clear)
key
:
Press
this
key
to
delete
the
registered
data.
@
ENTER
key
Used
for
executing
the
entry.
@
TOTAL
key
After
this
key
is
pressed,
the
display
shows
the
time
from
the
start
point
to
the
current
OUT
point
of
the
event
on
the
RECORDER
tape.
If
no
OUT
point
of
the
RECORDER
has
been
registered,
the
time
to
the
IN
point
of
the
RECORDER
will
be
shown
on
the
display.
Also,
the
error
code
js
displayed
on
the
PLAYER
display.
(See
pages
55
and
72.)
@
A/B
ROLL
key/lamp
Press
this
key
to
set
the
unit
to
the
A/B
mode.
In
this
mode,
two
PLAYERs
can
be
used
for
an
edit.
When
the
unit
is
set
to,
the
normal
mode,
this
lamp
will
go
out.
®
TCG
SET
key
:
Used
to
set
the
TC
(time
code).
@
EVENT
key
be
Press
this
key
to
set
or
change
event
numbers.
DUR
(Duration)
key
Press
this
key
to
check
the
time
length
of
an
edit.
(See
page
59.)
@
AUDIO
SPLIT
key/lamp
Press
this
key
to
enter
audio
edit
points
only.
After
these
points
have
been
entered,
the
lamp
goes
out
and
the
video
edit
points
can
be
entered.
@
ASSEM
key/lamp
Press
this
key
to
execute
assemble
editing.
®
V,
A1,
A2,
TC
keys/lamps
Used
in
the
insert
editing
mode.
V:
Press
to
select
the
video
signal.
Ai:
Press
to
select
the
signa!
of
Audio
Channel!
1.
A2:
Press
to
select
the
signal
of
Audio
Channel
2,
TC:
Press
to
select
the
time
code
signal.
Note:
This
key
can
not
be
used
when
a
34-pin
I/F
Board
has
been
installed
in
the
RECORDER
VTR.
©
EDIT
POINT
Entry
lamp
Lights
up
when
an
edit
point
is
entered.
(See
page
57.)
@
EDIT
POINT
(IN/
A
OUT/
B
IN/
OUT)
Selection
keys
Used
to
enter
or
check
the
edit
points.
@
PREVIEW
key/lamp
Used
to
rehearse
the
editing
process.
