Colour Set Display
1. Chroma Level Adjustment
[Chroma Level: –3 to +3]
Chroma Level can be decreased or increased to three
levels.
2. White Balance Setting
[ White Bal: ATW, AWC A, AWC B, P SET 3 200K,
P SET 5 600K]
ATW: The white balance is automatically adjusted to
the optimum position.
AWC A, AWC B: Colour temperature conditions at
two points can be stored at AWC A and AWC B.
Once the white balance is adjusted with the
ITEM/AWC switch on the back of the camera, it
is no longer necessary to set the white balance
again if you simply select AWC A or AWC B,
provided that the camera is used under the same
conditions.
Fine colour adjustment can be made after setting
AWC by red/blue gain adjustment in Painting
Setting or by the red and blue gain adjustment
controls (R/B GAIN dials) from the RCU (ROP).
P SET 3 200K: The white balance is adjusted to
3 200K illumination.
P SET 5 600K: The white balance is adjusted to
5 600K illumination.
3. ATW Speed Setting
[ATW Speed: SLOW 2, SLOW 1, MID, FAST 1,
FAST 2]
ATW Speed can be set.
4. Black Level Setting [Pedestal: –150 to +150]
The black level (pedestal) of the luminance (Y) signal
can be set. Used in adjusting the black levels of two or
more cameras.
5. Painting Setting
[ Painting: R Gain, B Gain, R Pedestal, B Pedestal:
–150 to +150]
R Gain, B Gain: Fine adjustment of the white balance
can be made after AWC setting when AWC A or
AWC B is selected in White Balance Setting.
In case of using the RCU (ROP), use the red and
blue gain adjustment controls (R/B GAIN dials)
for this purpose. The set value returns to ±0 after
AWC setting in using the camera alone.
Neither P SET 3 200K nor P SET 5 600K can
be set from the RCU, ROP or the multi hybrid
control panel.
Note
