Panasonic BL-C230A

42
BL-C230A
9.1.5. How To Remove Chassis [No.5] (Procedure No.1→2→3→4→5)
9.1.6. How To Remove Sensor Board [No.6] (Procedure No.1→2→3→4→5→6)
1. Remove four Screws (D).
2. Remove the Chassis from the Front Cabinet.
1. Remove the Sensor Board from the Front Cabinet.
