BL-C230A
IC107 C0DBAYY00555 IC
IC301 C1CB00002566 IC
IC302 C0DBFYY00034 IC
IC303 C0GBE0000015 IC
IC304 C0DBFYY00103 IC
(TRANSISTORS)
Q104 B1CFFB000001 TRANSISTOR(SI)
Q105 B1CFFB000001 TRANSISTOR(SI)
Q106 PQVTDTA143TU TRANSISTOR(SI) S
Q107 PQVTDTA143TU TRANSISTOR(SI) S
(DIODE)
D101 MA8043 DIODE(SI) S
(CAPACITORS)
C101 ECUE1C104ZFQ 0.1
C102 ECUE1C104ZFQ 0.1
C103 ECUE1C104ZFQ 0.1
C105 ECUE1C104ZFQ 0.1
C107 ECUE1C104ZFQ 0.1
C108 ECUE1C104ZFQ 0.1
C109 ECUE1C104ZFQ 0.1
C111 ECUE1C104ZFQ 0.1
C113 ECUE1C104ZFQ 0.1
C115 ECUE1C104ZFQ 0.1
C117 ECUE1C104ZFQ 0.1
C119 ECUE1C104ZFQ 0.1
C122 ECUE1C104ZFQ 0.1
C124 ECUE1C104ZFQ 0.1
C127 ECUE1C104ZFQ 0.1
C129 ECUE1C104ZFQ 0.1
C130 ECUE1C104ZFQ 0.1
C132 ECUE1C104ZFQ 0.1
C134 ECUE1C104ZFQ 0.1
C135 ECUV0J105KBV 1
C136 ECUE1H101JCQ 100p
C137 ECUE1H101JCQ 100p
C138 ECUE1C104ZFQ 0.1
C139 ECUE1H101JCQ 100p
C142 ECUE1C104ZFQ 0.1
C143 ECUE1C104ZFQ 0.1
C144 ECUE1C104ZFQ 0.1
C145 ECUE1C104ZFQ 0.1
C146 ECUE1C104ZFQ 0.1
C147 ECUE0J105KBQ 1
C148 F1J0J1060006 10
C149 ECUE0J105KBQ 1
C150 ECUE0J105KBQ 1
C151 F1J0J1060006 10
C152 ECUE1H3R0CCQ 3
C153 ECUE1H2R0CCQ 2
C154 ECUE1C104ZFQ 0.1
C155 ECUE1C103KBQ 0.01
C156 ECUE1C104ZFQ 0.1
C157 ECUE1C104ZFQ 0.1
C159 ECUE1C104ZFQ 0.1
C160 F1J0J1060006 10
C161 ECUE1C104ZFQ 0.1
C162 ECUE1C104ZFQ 0.1
C164 ECUE1C104ZFQ 0.1
C165 ECUE1C104ZFQ 0.1
C169 ECUE1C104ZFQ 0.1
C170 ECUE1C104ZFQ 0.1
C173 ECUE1C104ZFQ 0.1
C175 ECUE1C104ZFQ 0.1
C176 ECUE1C104ZFQ 0.1
C177 ECUE1C104ZFQ 0.1
C179 ECUE1C104ZFQ 0.1
C180 ECUE0J105KBQ 1
C181 ECUE1C104ZFQ 0.1
C182 ECUE1C104ZFQ 0.1
C183 ECUE1C104ZFQ 0.1
Safety Ref.
No.
Part No. Part Name & Description Remarks
C184 ECUE1C104ZFQ 0.1
C186 ECUE1C104ZFQ 0.1
C188 ECUE1C104ZFQ 0.1
C189 ECUE1C104ZFQ 0.1
C190 ECUE1C104ZFQ 0.1
C192 ECUE1C104ZFQ 0.1
C198 ECUE1C104ZFQ 0.1
C199 ECUE1C104ZFQ 0.1
C200 ECUE1C104ZFQ 0.1
C201 ECUE1C104ZFQ 0.1
C202 ECUE1C104ZFQ 0.1
C203 ECUE1H101JCQ 100p
C204 F1J0J1060006 10
C205 F1J0J2260004 22
C206 ECUE1C104ZFQ 0.1
C301 F1J0J1060006 10
C302 F1J0J1060006 10
C303 ECUE1C104ZFQ 0.1
C304 ECUE1C104ZFQ 0.1
C305 ECUE0J105KBQ 1
C306 ECUE1C104ZFQ 0.1
C307 ECUE1H101JCQ 100p
C308 ECUE1C104ZFQ 0.1
C309 ECUE1H100CCQ 10p
C310 ECUE1C104ZFQ 0.1
C311 ECUE1C104ZFQ 0.1
C312 ECUE1H9R0CCQ 9
C315 ECUE0J105KBQ 1
C316 ECUE1C104ZFQ 0.1
C319 ECUE1C104ZFQ 0.1
C320 F1J0J1060006 10
C326 ECUE1H102KBQ 0.001
C327 ECUE1H102KBQ 0.001
C328 ECUE1C104ZFQ 0.1
C329 ECUE1C104ZFQ 0.1
C330 ECUE1C104ZFQ 0.1
C331 ECUE1C104ZFQ 0.1
C333 ECUV1C105KBV 1
C334 F1J0J1060006 10
C335 ECUE1C104ZFQ 0.1
C336 ECUE1C104ZFQ 0.1
C337 ECUE1C104ZFQ 0.1
C338 F1J0J1060006 10
C339 F1H0G4750001 4.7
C340 F1H0G4750001 4.7
C341 ECUE1C104ZFQ 0.1
C342 F1H0G4750001 4.7
C343 ECUE1C104ZFQ 0.1
C344 F1J0J1060006 10
C345 ECUE1C104ZFQ 0.1
C346 ECUE1C104ZFQ 0.1
C347 F1H0G4750001 4.7
C348 ECUE1C104ZFQ 0.1
C351 ECUE1C104ZFQ 0.1
C352 ECUE1C104ZFQ 0.1
C354 ECUE1C104ZFQ 0.1
(CONNECTORS)
CN301 K1MN30B00137 CONNECTOR
CN302 K1MN30B00137 CONNECTOR
CN303 K1MY04AA0057 CONNECTOR
CN304 K1MN21BA0184 CONNECTOR
CN305 K1KB20A00142 CONNECTOR
(COILS AND CERAMIC FIL-
TERS)
L101 J0JBC0000071 CERAMIC FILTER
L102 J0JBC0000071 CERAMIC FILTER
L103 J0JBC0000071 CERAMIC FILTER
L104 G1C4R7MA0203 COIL
L105 G1C4R7MA0203 COIL
L106 J0JBC0000071 CERAMIC FILTER
L107 G1C100KA0066 COIL
