16.3.4. Sensor Board Parts
L111 J0JYC0000061 IC FILTER
L112 J0JYC0000053 IC FILTER
L301 G1C100K00031 COIL
L302 G1C1R0JA0041 COIL
L303 J0JYC0000047 IC FILTER
L304 J0JYC0000047 IC FILTER
L305 J0JBC0000071 CERAMIC FILTER
L314 G1C100KA0066 COIL
(RESISTORS)
R101 ERJ2GEJ472X 4.7k
R103 ERJ2RKF2402 24k
R104 ERJ2GEJ473 47k
R105 ERJ2GEJ473 47k
R108 ERJ2GEJ103 10k
R110 ERJ2GEJ473 47k
R111 ERJ2GEJ473 47k
R112 ERJ2GEJ122 1.2k
R115 ERJ2RKF4301 4.3k
R118 ERJ2RKF1002 10k
R119 ERJ2GE0R00 0
R121 ERJ2GEJ103 10k
R122 ERJ2GEJ103 10k
R127 ERJ2GEJ105X 1M
R128 ERJ2GEJ101 100
R146 ERJ2GEJ103 10k
R148 ERJ2GEJ103 10k
R151 ERJ2GEJ330 33
R152 ERJ2GEJ330 33
R153 ERJ2GEJ473 47k
R164 ERJ2GEJ102 1k
R165 ERJ2GEJ102 1k
R166 ERJ2GEJ102 1k
R167 ERJ2GEJ102 1k
R186 ERJ2GEJ102 1k
R187 ERJ2GEJ102 1k
R195 ERJ2GEJ473 47k
R197 ERJ2GEJ103 10k
R301 ERJ2GEJ103 10k
R302 ERJ2RKF6491 6.49k
R303 ERJ2GEJ105X 1M
R304 ERJ2GEJ102 1k
R306 ERJ3EKF49R9 49.9
R307 ERJ3EKF49R9 49.9
R308 ERJ3EKF49R9 49.9
R309 ERJ3EKF49R9 49.9
R310 ERJ2GE0R00 0
R327 ERJ2GEJ562X 5.6k
R328 ERJ2GEJ821 820
R329 ERJ2GE0R00 0
R334 ERJ2GEJ470 47
R335 ERJ2GE0R00 0
R336 ERJ2GE0R00 0
R340 ERJ2GEJ121 120
R341 ERJ2GEJ121 120
R342 ERJ2GEJ121 120
R343 ERJ2GEJ121 120
R362 ERJ2GEJ562X 5.6k
R363 ERJ2GEJ562X 5.6k
R367 ERJ2GEJ103 10k
R385 ERJ2GEJ331 330
R388 ERJ2GEJ104 100k
R389 ERJ2GEJ103 10k
R390 ERJ2GE0R00 0
(COMPONENTS PARTS)
RA101 D1H84734A024 RESSISTOR ARRAY
RA102 D1H84734A024 RESSISTOR ARRAY
RA103 D1H84734A024 RESSISTOR ARRAY
RA104 D1H84734A024 RESSISTOR ARRAY
RA305 D1H84704A024 RESSISTOR ARRAY
RA306 D1H84704A024 RESSISTOR ARRAY
Safety Ref.
No.
Part No. Part Name & Description Remarks
(SWITCHES)
SW101 K0H1BB000094 PUSH SWITCH
SW301 K0D122A00098 SLIDE SWITCH
SW302 K0D122A00098 SLIDE SWITCH
(CRYSTAL OSCILLATORS)
X101 H0J240500062 CRYSTAL OSCILLATOR
X301 H0J250500061 CRYSTAL OSCILLATOR
Safety Ref.
No.
Part No. Part Name & Description Remarks
PCB2 PNWP2C230A SENSOR BOARD ASS’Y (RTL)
(ICS)
IC701 C0JBAS000229 IC
IC702 C1AB00003196 IC
IC703 C0ABBA000186 IC
IC704 L2CD00000045 PHOTO ELECTRIC TRANS-
DUCER
(TRANSISTORS)
Q701 PQVTDTC143E TRANSISTOR(SI) S
Q702 PQVTDTC143E TRANSISTOR(SI) S
Q703 PQVTDTC143E TRANSISTOR(SI) S
Q704 PQVTDTC143E TRANSISTOR(SI) S
(DIODES)
D703 MA111 DIODE(SI) S
LED701 PQVDBRPY1204 DIODE(SI) S
LED702 PQVDBRPY1204 DIODE(SI) S
(CAPACITORS)
C701 F1H0G4750001 4.7
C702 ECUE1C104ZFQ 0.1
C703 ECUE1C104ZFQ 0.1
C704 ECUE1C104ZFQ 0.1
C705 F1J0J2260004 22
C706 ECUE1C104ZFQ 0.1
C707 ECUE1A104KBQ 0.1
C708 F1H0G4750001 4.7
C709 F1G0J225A008 2.2
C710 F1J0J1060006 10
C711 ECUE1H222KBQ 0.0022
C712 ECUV1A224KBV 0.22
C713 F1H0G4750001 4.7
C718 F1J0J2260004 22
C719 F1J0J2260004 22
C720 ECUE1A104KBQ 0.1
C721 ECUV1C105KBV 1
C722 ECUE1C104ZFQ 0.1
C723 ECUE0J105KBQ 1
C725 ECUE1A104KBQ 0.1
C726 ECUE1H102KBQ 0.001
C728 F1J0J2260004 22
C729 F1J0J2260004 22
C730 ECUE1C223KBQ 0.022
C731 ECUE1H102KBQ 0.001
C733 ECUE1H102KBQ 0.001
C783 ECUE1H101JCQ 100p
C784 ECUE1H101JCQ 100p
C785 ECUE1H101JCQ 100p
(CONNECTORS)
CN701 K1MN21AA0058 CONNECTOR
CN702 K1KA02AA0229 CONNECTOR
(COILS AND CERAMIC FIL-
TERS)
L701 G1C4R7MA0098 COIL
R733 J0JYC0000060 IC FILTER
R734 J0JYC0000060 IC FILTER
Safety Ref.
No.
Part No. Part Name & Description Remarks
