● Replacing the Air Purifying Filters
■ Reinstalling the air purifying filters
■ Removing the air purifying filters
1 Open the filter frame to insert the new filters.
2 Insert the new air purifying filter.
(Be sure the “FRONT” mark is facing you)
3 Push until you hear a click.
4 Reinsert the air filters.
5 Close the front panel after reinstalling the air
purifying filters.
Caution - Be careful not to hurt your hands on metal parts.
(Once every 3 month)
• Do not reuse dirty filters. Consult the nearest authorized dealer. (Air Purifying filter No. CZ-SF5N)
• These filters function effectively for not more than three months.
• If the air conditioner operates with dirty filters:-
- Air is not purified
- Cooling capacity decreases
- Foul odours are emitted
1 Raise the front panel to its full extent.
2 Remove the air filters (left and right).
• Lift up slightly then pull down
3 Hold the tabs of the air purifying filters and pull.
!
Press here
