Panasonic CS-A73KR - Electronic Parts List

NO. DESCRIPTION & NAME Q’TY CU-A123KR REMARKS
1 CHASSY ASS’Y 1 CWD50K659A
2 FAN MOTOR BRACKET 1 CWD54254
3 SCREW - FAN MOTOR BRACKET 2 CWH55189
4 FAN MOTOR 1 CWA95381 0
5 SCREW - FAN MOTOR MOUNT 4 CWH55406
6 COMPRESSOR 1 2KS224D5CA02 0
7 ANTI - VIBRATION BUSHING 3 CWH50055
8 NUT - COMPRESSOR MOUNT 3 CWH4582065
9 CONDENSER 1 CWB32C336
10 4-WAY VALVE 1 CWB00003 0
11 TUBE ASS’Y (CHECK VALVE / CAPILLARY) 1 CWT01C652
12 HOLDER COUPLING ASS’Y 1 CWH35K063
13 3-WAY VALVE 1 CWB01480 0
14 2-WAY VALVE 1 CWB02308 0
15 STRAINER 1 CWB11025
16 V - COIL COMPLETE 1 CWA43C2008 0
17 SOUND PROOF BOARD 1 CWH15288
18 SOUND PROOF MATERIAL 1 CWG30911
19 WIRE NET 1 CWD04197A
20 AIR GUIDER PROPELLER FAN 1 CWD31138
21 OVERLOAD PROPECTOR 1 CWA12360 0
22 HOLDER - O.L.P. 1 CWH7041200
23 TERMINAL COVER 1 CWH17006
24 NUT - TERMINAL COVER 1 CWH7080300
25 TEMPERATURE RELAY 1 CWA14C1001 0
26 CONTROL BOARD 1 CWH10972
27 TERMINAL BOARD ASS’Y 1 CWA28K216
28 ELECTROLYTIC CAPACITOR 1 CWA32C045 0
29 TERMINAL BOARD ASS’Y 1 CWA4711012
30 CAPACITOR - COMPRESSOR 1 CWA31647
(30 F, 370V)
0
31 HOLDER CAPACITOR 1 CWH30057
32 CAPACITOR - FAN MOTOR 1 CWA31604
(1.5 F, 400V)
0
33 ELECTROMAGNETIC SWITCH 2 CWA00059 0
34 ELECTROLYTIC CAPACITOR 1 CWA32C067 0
35 PROPELLER FAN ASS’Y 1 CWH00K087
36 NUT - PROPELLER FAN 1 CWH56053
37 CABINET SIDE PLATE (RIGHT) 1 CWE04217A
38 CABINET SIDE PLATE ( LEFT) 1 CWE04220A
39 CABINET FRONT PLATE 1 CWE06K104A
40 HANDLE 1 CWE16037C
41 CONTROL BOARD COVER 1 CWH13461
42 PLATE FOR CONTROL BOARD COVER 1 CWD91258
43 CABINET TOP PLATE 1 CWE03K035A
(Note)
- All parts are supplied from MACC, Malaysia (Vendor Code: 086).
- “O” marked parts are recommended to be kept in stock.
21. Electronic Parts List
87
