Panasonic CS-A73KR

Accessories: Flaring piping kit
CZ-3F5, 7AEN
SELECT THE BEST LOCATION
INDOOR UNIT
- There should not be any heat source or steam near the unit.
- There should not be any obstacles blocking the air circulation.
- A place where air circulation in the room is good.
- A place where drainage can be easily done.
- A place where noise prevention is taken into consideration.
- Do not install the unit near the door way.
- Ensure the spaces indicated by arrows from the wall, ceiling, or
other obstacles.
- Indoor unit of this room air conditioner shall be installed on the
wall in a height of at least 2.3 m.
OUTDOOR UNIT
- If an awning is built over the unit to prevent direct sunlight or rain,
be careful that heat radiation from the condenser is not obstructed.
- There should not be any animal or plant which could be affected by
hot air discharged.
- Keep the spaces indicated by arrows from wall, ceiling, fence or
other obstacles.
- Do not place any obstacles which may cause a short circuit of the
discharged air.
- If piping length is over the common length, additional refrigerant
should be added as shown in the table.
Piping size
Common
Length
Max.
Elevation
(m)
Max.
Piping
Length
(m)
Additional
Refrigerant
(g/m)
Model Gas
Liquid
A73KR/A93KR 3/8” 1/4” 7.5 5 10 20
A123KR 1/2” 1/4” 7.5 5 15 20
Indoor/Outdoor unit installation diagram
