Electrical Data Input W Cooling; 660 - 610
Heating; 640 - 580
Running Current A Cooling; 3.2 - 3.0
Heating; 3.0 - 2.8
COP/EER W/W Cooling; 3.20 - 3.38
Heating; 3.59 - 3.88
Starting Current A 11.2
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 3/8”
L ; Half Union 1/4”
G ; 3-way
valve
L ; 2-way
valve
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 3/8”
L ; (liquid side) 1/4”
G ; (gas
side)
L ; (liquid
side)
Drain
Hose
Inner diameter mm 12 —
Length m 0.7 —
Power Cord Length
Number of core-wire
m 2.0
3 (1.0 mm
2
)
—
—
Dimensions Height inch (mm) 10 - 31/32 (279) 18 - 29/
Width inch (mm) 31 - 15/32 (799) 30 - 23/
Depth inch (mm) 7 - 15/32 (190) 9 - 21/32
(
Net Weight lb (kg) 20 (9.0) 64 (
29.0)
Compressor Type — Rotary (1
cylinder)
rolling
piston
Motor Type — Induction (
2
Rated Output W — 550
Air Circulation Type Cross-flow Fan
Propeller
Material AS + Glass Fiber 30% AES + Glass
Fiber
Motor Type Induction (4-poles) Induction (
6
Input W 29.0 - 27.0 65.8 -
57.5
Rate Output W 10 20
Fan Speed Low rpm 810 - 770 —
Medium rpm 940 - 890 —
High rpm 1,050 - 1,010 755 -
730
SuperHigh rpm 1,190 - 1,160 —
Heat Exchanger Description Evaporator
Condenser
Tube material Copper
Copper
Fin material Aluminium (Pre Coat) Aluminium (
Pre
Fin Type Slit Fin
Louver
Row / Stage (Plate fin configuration, forced
draft)
2 × 14 1 ×
18
FPI 18 19
Size (W × H × L) mm 614 × 294 × 25.4 856 ×
457.2
Refrigerant Control Device —
Capillary
5
