4. Location of Controls and Components
4.1 Indoor Unit
4.1.1 CS-PC12TKF
Vertical Airflow
Direction Louver
• Do not adjust by hand.
Air Filters
Auto OFF/ON button
• Use when remote control is
misplaced or a malfunction occurs.
INDICATOR
(Green)
(Orange)
POWER
TIMER
(Orange)
JETSTREAM
(Orange)
SLEEP
Remote Control Receiver
Maximum distances: 8m
Horizontal airflow direction louver
• Manually adjustable.
Front Panel
Aluminium Fin
4.1.2 CS-PC18TKF CS-PC24TKF
Front Panel
Horizontal airflow direction louver
• Manually adjustable.
INDICATOR
(Green)
(Orange)
Auto OFF/ON button
• Use when remote control is misplaced
or a malfunction occurs.
Aluminium Fin
Vertical Airflow
Direction Louver
• Do not adjust by hand.
Remote Control Receiver
Maximum distances: 8m
POWER
TIMER
(Orange)
JETSTREAM
(Orange)
SLEEP
Air Filters
4.2 Outdoor Unit
Air inlet (rear)
A
ir inlet (side)
Air outlet
