Panasonic CS-PC12TKF User Manual

14
5.2 Outdoor Unit
5.2.1 CU-PC12TKF
(18)
69.5 61.6
542
28939
570
22
(104.7)
67.6
780
85.5
155.2 34.3
60.5104.9
Space necessary
for installation
Anchor Bolt Pitch
320 × 570
1000 mm
100 mm
100 mm
<Side View>
<Side View>
<Front View>
<Top View>
Unit: mm
2-way valve at
Liquid side
(High Pressure)
3-way valve at
Gas side
(Low Pressure)
5.2.2 CU-PC18TKF
3-way valve at Gas side
(Low Pressure)
2-way valve at Liquid side
(High Pressure)
(124) 540 160 37
37 299
32167
330
619
1836269
(20)
357
824 63
22
Anchor Bolt Pitch
330 x 540
Space necessary for
installation
<Side View>
10cm
10cm
100cm
<Side View>
<Top View>
<Front View>
Unit : mm
