Panasonic CS-PC12TKF

15
5.2.3 CU-PC24TKF
(25)
70.5
75
695
542
320
386
45
7.7
613
34.7
(131)
875
3582
360.5
131
72
Space necessary for
installation
Anchor Bolt Pitch
360.5 × 613
100 cm
10 cm
10 cm
<Side View>
<Side View>
<Front View>
<Top View>
Unit: mm
2-way valve at Liquid side
(High Pressure)
3-way valve at Gas side
(Low Pressure)
