16
6. Refrigeration Cycle Diagram
COMPRESSOR
3-WAY
VALVE
GAS
SIDE
LIQUID
SIDE
CAPILLARY
TUBE
HEAT EXCHANGER
(CONDENSER)
2-WAY
VALVE
PIPE
TEMP
SENSOR
INTAKE
AIR
TEMP
SENSOR
HEAT EXCHANGER
(EVAPORATOR)
INDOOR OUTDOOR
STRAINER
THERMOSTAT
(PC24TK only)
