12.1.2 Cooling Operation Time Diagram (For PC18/24TKF)
Hi Hi Hi
Hi
Lo Lo Lo
a
bcdef gh i j k
l
m
nopqr s t uvwxyz
ON
OFF
Set Temp.
Outdoor Temp.
31°C
29°C
1.5K
Intake
Temp.
10°C
Pipe Temp.
2°C
<Description of operation>
d - g
a -b, g - h, o - p
q - t
v - y
h - o
: restart control (waiting for 3 min.)
: 60 sec. Forcible operation.
: freeze prevention control.
: outdoor fan control.
: 7 min. time save control.
Operation
Stop
Compressor
Basic time
Indoor Fan
Outdoor Fan
Operation LED
1’3’ 4’7’
1’
1’
