11
2.4 CU-3E23SBE
Item Unit OUTDOOR UNIT
Indoor Unit Combination 1.6kW + 2.0kW + 2.8kW
Power Source 1 Phase, 230V, 50Hz (Power supply from outdoor unit)
Cooling Operation
Capacity
kW 6.8 (1.90 ~ 8.00)
BTU/h 23200 (6480 ~ 27300)
Electrical
Data
Running Current A 8.40
Power Input kW 1.91 (270 ~ 2.37)
EER W/W 3.56 (7.04 ~ 3.38)
Annual Consumption kWh 340
Noise
Sound Pressure Level dB-A (H/L) 50 / -
Sound Power Level dB (H/L) 64 / -
Heating Operation
Capacity
kW 8.5 (3.30 ~ 10.40)
BTU/h 29000 (11300 ~ 35500)
Electrical
Data
Running Current A 9.6
Power Input kW 2.09 (x.xx ~ x.xx)
COP W/W 4.07 (5.32 ~ 3.74)
Annual Consumption kWh 1820
Noise
Sound Pressure Level dB-A (H/L) 51 / -
Sound Power Level dB (H/L) 65 / -
Maximum Current A 15.6
Starting Current A 8.4
Maximum Input Power W 3.55k
Extra Low Temperature
Capacity kW 4.45
Input Power W 2450
COP W/W 1.82
Dimension
Height mm 795
Width mm 875 (+95)
Depth mm 320
Net Weight kg 71
Pipe Length Range (1 room) m 3 ~ 25
Maximum Pipe Length (Total Room) m 60
Piping
Standard Length m 5
Height Difference m 15
Add. Gas Amount g/m 20
Pipe Length for Add. Gas m 30
Refrigerant Pipe Diameter
Liquid Side mm (inch) 6.35 (1/4)
Gas Side mm (inch) 9.52 (3/8)
Compressor
Type Hermetic Motor / Rotary
Motor Type Brushless (4-poles)
Rated Output W 1.30k
Air Circulation
Type Propeller Fan
Motor Type DC Motor (8-poles)
Rated Output W 60
Fan Speed High (Cooling / Heating) RPM 600 / 680
