7
2.2 CU-2E15SBE
Item Unit OUTDOOR UNIT
Indoor Unit Combination 2.0kW + 2.5kW
Power Source 1 Phase, 230V, 50Hz (Power supply from outdoor unit)
Cooling Operation
Capacity
kW 4.5 (1.5 ~ 5.2)
BTU/h 15300 (5120 ~ 17700)
Electrical
Data
Running Current A 5.75
Power Input kW 1.23 (0.25 ~ 1.52)
EER W/W 3.66 (6.00 ~ 3.42)
Annual Consumption kWh 242
Noise
Sound Pressure Level dB-A (H/L) 47 / -
Sound Power Level dB (H/L) 62 / -
Heating Operation
Capacity
kW 5.4 (1.1 ~ 7.0)
BTU/h 18400 (3750 ~ 23900)
Electrical
Data
Running Current A 5.20
Power Input kW 1.17 (0.21 ~ 1.67)
COP W/W 4.62 (5.24 ~ 4.19)
Annual Consumption kWh 1400
Noise
Sound Pressure Level dB-A (H/L) 49 / -
Sound Power Level dB (H/L) 64 / -
Maximum Current A 12.0
Maximum Input Power W 2.73k
Starting Current A 5.75
Dimension
Height mm 619
Width mm 824 (+70)
Depth mm 299
Net Weight kg 39
Pipe Length Range (1 room) m 3 ~ 20
Maximum Pipe Length (Total Room) m 30
Piping
Standard Length m 5
Height Difference m 10
Add. Gas Amount g/m 15
Pipe Length for Add. Gas m 20
Refrigerant Pipe Diameter
Liquid Side mm (inch) 6.35 (1/4)
Gas Side mm (inch) 9.52 (3/8)
Compressor
Type Hermetic Motor / Rotary
Motor Type Brushless (6-poles)
Rated Output W 900
Fan Motor
Type Propeller Fan
Motor Type DC Motor (8-poles)
Rated Output W 40
Fan Speed High (Cooling / Heating) RPM 800 / 930
Heat Exchanger
Type Plate fin configuration forced draft type
Tube Material Copper
Fin Material Aluminum (Pre Coat)
Row / Stage 2 / 28
FPI 17
