Panasonic Diga DMR-EZ27EB User Manual

47
RQT8856
Setting Menus
Tips
To browse through the list
Press [1 2 CH].
Auto-Setup Restart
You can restart auto channel setting for terrestrial digital channels
if set up (➔ 10) fails for some reason.
However, if you perform “Auto-Setup Restart”, all channel settings
and all created profiles are deleted.
Press [w] to select “Yes” then press [OK].
Tips
You can also use the following method to restart Auto-Setup.
(All the settings except for the ratings level, ratings
password, Owner ID and Clock return to the factory preset.
The timer recording programmes are also cancelled.)
1. When the unit is turned on and stopped, press and hold
[CH 1] and [CH 2] on the main unit simultaneously for
about 5 seconds.
The Power Save (➔ 52) confirmation screen appears.
2. Press [e, r] to select “On” or “Off” then press [OK].
•
DVB Manual Tuning
You can set channels manually that the DVB Auto Setup could not
complete successfully.
Setup
Tuning
Disc
Sound
Display
Connection
Others
Edit Profiles
Auto-Setup Restart
DVB Manual Tuning
Signal Condition
OK
SELECT
TAB
RETURN
Add New DVB Services
DVB Manual Tuning
Signal Strength
10
Prog.
Quality
Channel
Service Name
Net ID
TS ID
Signal Quality
10
Frequency
0
MHz
Channel System
0
RETURN
OFFSET
START SCAN
CHANNEL
United Kingdom
DVB CH21 474.1
1. Press [e, r] to select the channel you want to set.
2. Press [w, q] to adjust the frequency.
The frequency rises and falls in steps of 0.5 MHz.
Adjust the frequency by checking the signal strength and
signal quality displays.
[Refer to “Signal Condition” (➔ right) for signal strength and
signal quality.]
3. Press [OK] to start scan.
The set channel is displayed in the table.
Signal Strength
Signal Quality
Frequency
MHz
Channel System
1 22 ZDF 12290 514 7
2 22 3sat 12290 514 7
3 22 Doku/KiKa 12290 514 7
RETURN
OFFSET
START SCAN
CHANNEL
DVB Manual Tuning
3 services found.
10
10
0
0
United Kingdom
DVB CH21 474.1
Prog.
Quality
Channel
Service Name
Net ID
TS ID
4. Press [EXIT] and press [1 2 CH], check that
applicable channels have been selected.
–
–
Add New DVB Services
You can search for newly added terrestrial digital channels to
receive.
Setup
Tuning
Disc
Sound
Display
Connection
Others
Edit Profiles
Auto-Setup Restart
Signal Condition
OK
SELECT
TAB
RETURN
DVB Manual Tuning
Add New DVB Services
Add New DVB Services
Please wait! 8621 hC
ytilauQ.gorP Channel Service Name Net ID TS ID
RETURN
RETURN: to cancel
The unit starts searching for newly available terrestrial digital
channels. This takes about 5 minutes.
The bar over the table shows you the search progress.
At the end of the search, the number of found new digital
stations appears.
“No new services found.”, is displayed when
no new services can be found.
Press [OK] to save the newly found channels.
Tips
To cancel in middle
Press [RETURN].
The channels found before stopping are not saved.
–
–
–
Signal Condition
You can check the quality and strength of digital broadcast signals.
Realign the aerial if you are receiving a poor signal.
When “Signal Condition” is displayed in grey and cannot be
selected:
1 Press [EXIT] to exit the screen.
2 Press [1 2 CH] to select a digital channel. “D” appears on the
unit’s display.
3 Display the Setup menu again.
Setup
Tuning
Disc
Sound
Display
Connection
Others
Edit Profiles
Auto-Setup Restart
Add New DVB Services
OK
SELECT
TAB
RETURN
DVB Manual Tuning
Signal Condition
Signal Quality 010
Signal Strength 010
2 BBC 2
W DVB
CH30
RETURN
CH +
CH –
The quality and strength of the signal are shown.
Press [1 2 CH] to select the other channel.
Signal Quality
Below 2 (display red): The signal quality is so poor that there may
be interference in the pictures and sound.
2–5 (display orange): The signal quality is basically adequate,
but brief interference in the pictures and
sound is possible in isolated case.
Over 5 (display green): Optimum picture and sound quality.
Signal Strength
The display for signal strength is grey. “0” means signal strength
0%, “10” means signal strength 100%.
If the signal is too strong, the display will change from grey to red.
Reduce the signal amplification at your aerial.
When the signal is weak:
check that the aerial is correctly positioned
adjust the aerial reception with “DVB Manual
Tuning” in the Setup menu (➔ left).
check that the current digital broadcast channel is
correctly broadcasting.
•
–
–
–
RQT8856-BDTP070306.indb47RQT8856-BDTP070306.indb47 2007/04/0417:49:272007/04/0417:49:27
