DMR-E53EG, E55EB/EG/EBL/EP
Scart P.C.B. (Component Side)
(REP3682A)
Scart P.C.B.
(COMPONENT SIDE)
D3901 C-7 C3916 A-8
Connector
C3917 A-8
JK3901 B-1 C3918 A-7
JK3904 B-5 C3919 B-7
JK3905 C-5 C3921 A-7
PS3901 A-2 C3924 B-7
PS3902 A-4 C3928 C-9
PS3903 A-8 C3929 C-9
C3931 C-9
C3909 B-3 C3932 D-9
C3910 B-9 C3933 D-8
C3911 B-9 C3935 C-8
C3914 C-7
C3915 B-7 R3924 C-7
Resisitor
Scart P.C.B.(Component Side)
Diode Capacitor
Capacitor
