12.2 When the unit does not operate normally
after replacing the Timer Microprocessor with
new one
TOP PREVIOUS NEXT
in order to transmit the
Step Operation Descriptions
1 While power is ON, short IC7508-4 pin (RESET)
and the GND.
“RESET (L)” is transmitted to the reset terminal of Timer Microprocessor
(IC7501-11 pin), then the unit operates normally.
