20 Replacement Parts List
TOP PREVIOUS NEXT
Notes:
*Important safety notice:
Components identified by
mark have special characteristics important for safety.
Furthermore, special parts which have purposes of fire-retardant (resistors), high-quality sound
(capacitors), low-noise (resistors), etc. are used.
When replacing any of components, be sure to use only manufactures specified parts shown in the parts
list.
*Warning: This product uses a laser diode. Refer to caution statements.
*Capacity values are in microfarads (μF) unless specified otherwise, P=Pico-farads (pF), F=Farads (F).
*Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM), 1M=1,000k (OHM).
*The marking (RTL) indicates the retention time is limited for this item. After the discontinuation of this
assembly in production, it will no longer be available.
*“<IA>”-“<IF>”, marks in Remarks indicate languages of instruction manuals. [<IA>: English/Spanish,
<IB>: German/Italian, <IC>:French/Netherlands, <ID>: Swedish/Danish, <IE>: English, <IF>: Polish]
*All parts except parts mentioned [AVC-SPC] in the Remarks column are supplied from PAVCG.
Parts mentioned [AVC-SPC] are supplied from PAVC-CSG (AVC-SPC).
Ref. No. Part No. Part Name & Description Pcs Remarks
01 CASING/ACCESSORY/PACKING
1 ETXMM506E4F POWER SUPPLY P.C.B. 1 (RTL)
2 REP3664A MAIN P.C.B. 1 (RTL)EG,E53
