Panasonic DMR-EZ47VP

14.1.3. Front (L) P.C.B.
Ref No.
MODE 1 2 3
STOP 4.8 0 4.9
IC7701
14.1.4. Front (R) P.C.B.
Ref No.
MODE E C B E C B E C B
STOP 0 5.1 0 0 0 4.8 0 5.1 0
QR27501 QR27503 QR27505
14.1.5. P56001 Connector
Ref No.
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
REC 3.3 3.3 0 3.3 0 4.9 0 4.8 0 0.1 0 0 0 3.0 0 5.0 0 3.3 4.1 0
PLAY 3.3 3.3 0 3.3 0 4.9 0 4.8 0 0.1 0 0 0 3.0 0 5.0 0 3.3 4.1 0
STOP 3.3 3.3 0 3.3 0 4.9 0 4.8 0 0.1 0 0 0 3.0 0 5.0 0 3.3 4.1 0
Ref No.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
REC 3.3 1.4 0 0 4.9 4.9 0 0 5.8 4.9 0 0 3.3 0 0 0 5.1 2.1 0 0
PLAY 3.3 1.4 0 0 4.9 4.9 0 0 5.8 4.9 0 0 3.3 0 0 0 5.1 2.1 0 0
STOP 3.3 1.4 0 0 4.9 4.9 0 0 5.8 4.9 0 0 3.3 0 0 0 5.1 2.1 0 0
Ref No.
MODE 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
REC 3.3 1.2 3.3 0 0 0 3.5 0.6 3.5 0 3.5 0.5 0 0 12.2 0.6 0 0 1.7 0.7
PLAY 3.3 1.2 3.3 0 0 0 3.5 0.6 3.5 0 3.5 0.5 0 0 12.2 0.6 0 0 1.7 0.7
STOP 3.3 1.2 3.3 0 0 0 3.5 0.6 3.5 0 3.5 0.5 0 0 12.2 0.6 0 0 1.7 0.7
Ref No.
MODE 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
REC 1.7 0 1.7 0.5 0 0 2.2 2.3 0 0 0 5.0 0 0 0 0 0 2.5 0 2.5
PLAY 1.7 0 1.7 0.5 0 0 2.2 2.3 0 0 0 5.0 0 0 0 0 0 2.5 0 2.5
STOP 1.7 0 1.7 0.5 0 0 2.2 2.3 0 0 0 5.0 0 0 0 0 0 2.5 0 2.5
Ref No.
MODE 81 82 83 84 85 86 87 88
REC 0 0 3.3 2.5 0 2.5 3.3 0
PLAY 0 0 3.3 2.5 0 2.5 3.3 0
STOP 0 0 3.3 2.5 0 2.5 3.3 0
P56001
P56001
P56001
P56001
P56001
101
DMR-EZ47VP / DMR-EZ475VP
