Getting started
SQT0134
13
• While writing to/reading from the media, do not switch the
unit to standby mode or remove the media. Such action
may result in loss of the media contents.
• When inserting the media, ensure that it is facing the right
way up.
1 SD card slot indicator
2 Copying indicator
3 Disc indicator
4 Drive (HDD, DVD or SD) indicator
5 Remote control signal indicator
6 Main display section indicator
- Current time
- Playback counter
- Various messages (> 93)
7 Playback indicator
8 USB port indicator
9 Timer recording indicator
• This indicator lights up when the timer
recording standby is activated.
Main unit
1 Standby/on switch (Í/I)
Press to switch the unit from on to standby
mode or vice versa. In standby mode, the unit
is still consuming a small amount of power.
2 Open/close disc tray
3 Disc tray
4 USB port
5 SD card slot
• When removing the SD card, press on the
centre of the card and pull it straight out.
Pull to flip down the
front panel.
6 Recording indicator
• The indicator will light up while recording.
• The indicator will blink while recording is
paused and before recording starts.
7 Remote control signal sensor
• Angle: Approx. 20° up and down, 30° left and
right
• Distance: Within approx. 7 m in front of the
unit
8 Channel select (> 21)
9 Start recording (> 25)
: Stop
; Start play
Display
PLAY
COPY
SD USB
HDDSDVD
123
45
6789
