• Connect to terminals of the same colour.
• 3D video playback is not possible with this connection.
• Do not connect video signals through a video recorder.
Due to copy guard protection the picture may not be
displayed properly.
• Connect to terminals of the same colour.
• VIERA Link function is possible by connecting to a TV or
amplifier/receiver compatible with VIERA Link.
• When using a TV or an amplifier/receiver that does not
display “ARC compatible” on the HDMI terminal, it is
necessary to connect the TV and the amplifier/receiver with
a digital audio cable to enjoy the TV audio on the
amplifier/receiver.
When the unit is not to be used for a long
time
To save power, unplug it from the household
mains socket. This unit consumes a small
amount of power, even when the unit is in
standby mode.
[approx. 0.2 W (“Quick Start” is not activated
and “RF OUT ( Aerial Signal )” is set to “Off”)]
AUDIO/VIDEO OUT terminals
Connect the Set Top Box or video equipment
AUDIO IN VIDEO IN
LR
Audio/Video cable
(supplied)
TV
Set Top Box or video equipment
Audio/Video cable
(supplied)
Amplifier/receiver connections
HDMI terminal
HDMI
HDMI INHDMI OUT
HDMI
cable
Amplifier/
receiver
TV
HDMI cable
(ARC compatible)
(ARC compatible)
3D programmes can be played back when
this unit is connected to a 3D compatible
amplifier/receiver and a 3D compatible TV.
• You will not be able to view 3D programmes
with this connection if your amplifier/receiver
is not 3D compatible.
