Specifications
Reference
Specifications are subject to change without
notice.
∫ General
Dimensions: 430 mm (W)
59 mm (H)
(excluding the projecting parts)
238 mm (D)
(including the projecting parts)
249 mm (D)
Mass: Approx. 2.9 kg
Power supply: AC 220 V to 240 V, 50 Hz
Power consumption: Approx. 28 W
Power consumption in standby mode:
“Quick Start” is activated and “Power Save
for Network Standby” is set to “Off”
Approx. 5 W
“Quick Start” is activated and “Power Save
for Network Standby” is set to “On”
Approx. 4 W
“Quick Start” is not activated and
“RF OUT ( Aerial Signal )” is set to “Off”
Approx. 0.2 W
Operating temperature: 5 oC to 40 oC
Operating humidity range: 10 % to 80 % RH
(no condensation)
∫ TV system
Tuner System: DVB-T
Country: Australia
Channel Coverage: VHF 6~12
UHF 27~69
∫ Recording system
DR mode: Partial TS
HG, HX, HE, HL, HM mode:
MPEG-4 AVC/H.264, Dolby Digital
XP, SP, LP, EP mode:
MPEG2 (Hybrid VBR), Dolby Digital
∫ Video/Audio terminals
Analog video input (pin jack): 1 pc.
Input level: 1 Vp-p (75 ≠)
Analog video output (pin jack): 1 pc.
Output level: 1 Vp-p (75 ≠)
Analog audio L/R input (pin jack): 1 pc.
Input level:
Full scale 2.0 Vrms at 1 kHz (> 10 k≠)
Analog audio L/R output (pin jack): 1 pc.
Output level:
Full scale 2.0 Vrms at 1 kHz (< 1 k≠)
Digital audio output (optical): 1 pc.
PCM, Dolby Digital, DTS
®
, MPEG
∫ HDMI terminal
HDMI output (19 pin type A): 1 pc.
PCM, MPEG, Dolby Digital, DTS
®
• This unit supports “HDAVI Control 5”
function.
∫ Internal HDD capacity
500 GB
∫ Other terminals
USB Port (Type A): 2 pcs.
SD Card Slot: 1 pc.
LAN (Ethernet) Port: 1 pc.
10BASE-T/100BASE-TX
