Panasonic DMR-XW480

Getting started
VQT2J62
14
Connection
≥Connect to terminals of the same colour.
≥Connect to terminals of the same colour.
COMPONENT VIDEO terminals can be used for either
interlace or progressive output (> 108) and provide a purer
picture than the VIDEO OUT terminal.
≥Connect to terminals of the same colour.
Required setting:
“Component Resolution” setting (> 81)
Other television connections
AUDIO/VIDEO terminals
AUDIO/VIDEO and S VIDEO
terminals
COMPONENT
VIDEO OUT
OUTAV1 I N
Y
R
P
B
P
R-AUDIO- L VIDEO S VIDEO
AUDIO IN VIDEO IN
LR
This unit’s rear
panel
Audio/Video cable
(included)
Television’s rear panel
COMPONENT
VIDEO OUT
OUTAV1 I N
Y
R
P
B
P
R-AUDIO- L VIDEO S VIDEO
AUDIO IN
R L
S VIDEO
IN
Audio/
Video cable
(included)
Television’s rear panel
This unit’s rear panel
S Video
cable
COMPONENT VIDEO terminals
COMPONENT
VIDEO OUT
OUTAV1 I N
Y
R
P
B
P
R-AUDIO- L VIDEO S VIDEO
P
R
P
B
Y
COMPONENT
VIDEO IN
Component video cable
Television’s rear panel
This unit’s rear
panel
