Panasonic KX-TDA100D

Connection Example
This diagram shows you a connection example.
External Sensor/
External Relay Device
Doorphone & Door Opener
External Music Source
Pager/
Speaker
Batteries
Voice Processing
System
PC
Printer
Telephone Company
Hybrid IP-PBX
PC
CSPS
Wireless Phone
Fax Machine
KX-T7636/
KX-T7633
PC
USB
ISDN Telephone
Amplifier
PC
SLT
DPT DSS Console
IP-PT
IP Softphone
CTI Server
Remote PC
KX-T7600 KX-T7600
PC
USB
KX-DT300
KX-DT300
Router
Private
IP Network
KX-DT346/
KX-DT343
