Panasonic KX-TDA200BX - Fixtures and Tools

Ref.
No.
Part No. Part Name & Description Remarks
R110 ERJ3GEYJ103 10k
R147 ERJ3GEYJ103 10k
R148 ERJ3GEYJ103 10k
R151 ERJ3GEYJ103 10k
R152 ERJ3GEYJ103 10k
R153 ERJ3GEYJ103 10k
R154 ERJ3GEYJ103 10k
R155 ERJ3GEYJ103 10k
R156 ERJ3GEYJ103 10k
R157 ERJ3GEYJ103 10k
R165 ERJ3GEYJ103 10k
R166 ERJ3GEYJ103 10k
R167 ERJ3GEYJ103 10k
R168 ERJ3GEYJ103 10k
R169 ERJ3GEYJ103 10k
R170 ERJ3GEYJ103 10k
R177 ERJ3GEYJ103 10k
R178 ERJ3GEYJ103 10k
R179 ERJ3GEYJ103 10k
R180 ERJ3GEYJ103 10k
R181 ERJ3GEYJ103 10k
R182 ERJ3GEYJ103 10k
R189 ERJ3GEYJ103 10k
R190 ERJ3GEYJ103 10k
R191 ERJ3GEYJ103 10k
R192 ERJ3GEYJ103 10k
R193 ERJ3GEYJ103 10k
R199 ERJ3GEYJ103 10k
R200 ERJ3GEYJ103 10k
R201 ERJ3GEYJ103 10k
R202 ERJ3GEYJ103 10k
R343 ERJ3GEYJ103 10k
R344 ERJ3GEYJ103 10k
R345 ERJ3GEYJ103 10k
(FILTERS)
L101 PFVF1A471SG CERAMIC FILTER
L102 PFVF1A471SG CERAMIC FILTER
L103 PFVF1A471SG CERAMIC FILTER
L104 PFVF1A471SG CERAMIC FILTER
L105 PFVF1A471SG CERAMIC FILTER
L106 PFVF1A471SG CERAMIC FILTER
L107 PFVF1A471SG CERAMIC FILTER
L108 PFVF1A471SG CERAMIC FILTER
L109 PFVF1A471SG CERAMIC FILTER
L110 PFVF1A471SG CERAMIC FILTER
L111 PFVF1A471SG CERAMIC FILTER
L112 PFVF1A471SG CERAMIC FILTER
(OTHER)
E21 PSHR1276Z SPACER
18.5. FIXTURES AND TOOLS
Ref.
No.
Part No. Part Name & Description Remarks
EC1 PSZZ1TDA100M EXTENSION BOARD (FOR CPU
CARD)
EC2 PSZZ2TDA100M EXTENSION BOARD (FOR LINE
CARD)
Note:
EC1 and EC2 are necessity for servicing.
80
KX-TDA200BX
