20.3. WAVEFORM
Waveform 1 Waveform 2 Waveform 3
Waveform 4
Waveform 5
Waveform 6
16.384MHz 32.768kHz
65.536MHz
16.384MHz
Switching the frequency of 20Hz/25Hz is
possible by the soft setting.
The abobe-mentioned waveform is the
example of 20Hz.
Switching the pulse spacing of 2976msec/3840msec
/4992msec/5120msec is possible by the soft setting.
The abobe-mentioned waveform is the example of
5120msec.
KX-TDA200BX
90
