4.1 Programming the IP-EXT Card
4.1.1 Assigning the IP Addressing Information
When an IP-EXT
card is placed on the LAN for the first time, it is necessary to assign IP addressing information
to the card. This is done by using the Maintenance Console.
Note
• It is assumed that you have already installed the Maintenance Console on your PC.
• The contents and design of the software are subject to change without notice.
• Microsoft product screen shot(s) reprinted with permission from Microsoft Corporation.
1. Start the Maintenance Console from the Start menu.
2. "Information before programming" appears.
a. Carefully read this important additional information,
which includes updates to this and other manuals.
b. Click OK to close this window.
3.
a. Enter
the Installer Level Programmer Code (default: IN-
STALLER).
b. Click
OK.
4. Click Connect.
5.
a. Select your PBX model from PBX Model.
b. Select the USB tab.
c. Enter the system password for installer (default: 1234).
d. Click Connect.
The system menu appears.
6.
a. Under Configuration, click Slot.
b. Move the mouse pointer over the
IP-EXT card. A menu
will be shown under the mouse pointer.
c. Click
OUS
to set the card to out-of-service status.
d. Move the mouse pointer over the IP-EXT card, then click
Card Property.
