Panasonic KX-TDA30

Note
• The AC adaptor supplied with the
PBX must be connected to DC IN 1. If an AC adaptor is connected
only to DC IN 2, the PBX will not start.
• If you need to connect an additional AC adaptor, plug the DC connector of the additional AC adaptor
into DC IN 2.
DC Connector
Additional
AC Adaptor
DC IN 2
AC Adaptor
1
2
3. Plug the AC cord into the AC adaptor, and then plug the other end into an AC outlet.
AC Adaptor
AC Cord
To AC outlet
Getting Started 21
3.1 Starting the PBX
