KX-TG1032S/KX-TG1033S/KX-TG1034S/KX-TGA101S
11.7. How to Check the Handset Speaker or Receiver
1. Prepare the digital voltmeter, and set the selector knob to ohm meter.
2. Put the probes at the speaker terminals as shown below.
11.8. Frequency Table (MHz)
Note:
Channel No. 2: In the Test Mode on Base Unit and Handset.
BASE UNIT HANDSET
Channel No Transmit Frequency Receive Frequency Transmit Frequency Receive Frequency
0 1928.448 1928.448 1928.448 1928.448
1 1926.720 1926.720 1926.720 1926.720
2 1924.992 1924.992 1924.992 1924.992
3 1923.264 1923.264 1923.264 1923.264
4 1921.536 1921.536 1921.536 1921.536
