KX-TG1032S/KX-TG1033S/KX-TG1034S/KX-TGA101S
15.5.3. Charger Unit
15.5.3.1. Cabinet and Electrical Parts
15.5.3.2. Main P.C.Board Parts
15.5.4. Accessories and Packing Materials
Note:
(*1) You can download and refer to the operating instruc-
tions (Instruction book) on TSN server.
15.5.4.1. KX-TG1032S
15.5.4.2. KX-TG1033S
C26 ECUV1C104KBV 0.1
C32 ECUE1A104KBQ 0.1
C34 ECUV1A105KBV 1
C35 ECUE1H101JCQ 100P
C39 ECUV1A105KBV 1
C40 ECUV1A105KBV 1
C41 ECUV1A105KBV 1
C42 ECUV1A105KBV 1
C43 ECUV1C104KBV 0.1
C44 ECUV1C104KBV 0.1
C45 ECUV1C104KBV 0.1
C46 ECUV1C104KBV 0.1
C47 ECUV1C104KBV 0.1
C48 ECUE1C103KBQ 0.01
C50 ECUE1H100DCQ 10P
C51 ECUE1H221JCQ 220P
C52 ECUE1H102KBQ 0.001
C53 ECUE1H151JCQ 150P
C56 ECUE1H100DCQ 10P
C57 ECUE1H390JCQ 39P
C58 ECUE1H102KBQ 0.001
C59 ECUE1H100DCQ 10P
C62 ECUE1H100DCQ 10P
C72 ECUE1H100DCQ 10P
C73 ECUE1H100DCQ 10P
C82 ECUE1H471KBQ 470P
C83 ECUE1H100DCQ 10P
C86 ECUV1A106ZF 10 S
C90 ECUE1H100DCQ 10P
C96 ECUE1H102KBQ 0.001
C97 ECUV1H100DCV 10P
C101 ECUE1A104KBQ 0.1
C107 ECUV1H100DCV 10P
C109 ECUV1H223KBV 0.022
C113 ECUE1H100DCQ 10P
C138 ECUE1H100DCQ 10P
C141 ECUE1H101JCQ 100P
C142 ECUE1H101JCQ 100P
C143 ECUE1H101JCQ 100P
C144 ECUE1H101JCQ 100P
C147 ECUE1C103KBQ 0.01
C148 ECUV1C104KBV 0.1
C150 ECUE1A104KBQ 0.1
C151 ECUE1A104KBQ 0.1
C156 ECUV1C104KBV 0.1
(OTHERS)
MIC L0CBAY000018 MICROPHONE
E101 L5DCAYY00005 LIQUID CRYSTAL DISPLAY (*2)
E102 PQHX11378Z COVER, LCD COVER SHEET
E103 PQHR11195Z TRANSPARENT PLATE, LCD PLATE PMMA-HB
E104 PQHR11205Z GUIDE, LCD ABS-HB
IC4 PQLP10291Z RF UNIT
CN4 K2HD103D0001 JACK
D8 D4ED1270A014 VARISTOR (SURGE ABSORBER)
X1 H0J103500021 CRYSTAL OSCILLATOR (*1)
Ref.
No.
Part No. Part Name & Description Remarks
200 PQLV30053ZS CHARGER UNIT ASS'Y (RTL) (for
TG1032S/1033S/1034S)
200 PQLV30053ZS1 CHARGER UNIT ASS'Y (RTL) (for
TGA101S)
200-1 PQKM10757Z1 CABINET BODY PS-HB
200-2 PQKF10741Z1 CABINET COVER (for TG1032S/
1033S/1034S)
PS-HB
200-2 PQKF10741Y1 CABINET COVER (for TGA101S) PS-HB
200-3 PQHA10023Z RUBBER PARTS, FOOT CUSHION
200-4 PQGT19555Z NAME PLATE (for TGA101S)
Ref.
No.
Part No. Part Name & Description Remarks
200-5 PQXDZLDRS1 MAGNET ELECTRIC TRANSDUCER,
SECURITY TAG (for TGA101S)
Ref.
No.
Part No. Part Name & Description Remarks
PCB200 PQWPTGA101CH MAIN P.C.BOARD ASS'Y (RTL)
(JACK)
J1 K2ECYB000001 JACK, DC S
(RESISTORS)
R1 ERDS1VJ100 10 S
R2 ERDS1TJ120 12 S
R3 ERDS1VJ100 10 S
R4 ERDS1TJ120 12 S
(OTHERS)
E201 PQJT10249Z CHARGE TERMINAL
Ref.
No.
Part No. Part Name & Description Remarks
A1 PQLV207V AC ADAPTOR (for Base Unit)
A2 PQLV209V AC ADAPTOR (for Charger Unit)
A3 PQJA10075Z CORD, TELEPHONE
A4 PQKE10456Z2 HANGER, BELT CLIP PC+ABS-
HB
A5 PQKL10088Z1 STAND, WALL MOUNT ABS-HB
A6 PQQX15791Y INSTRUCTION BOOK (for
English) (*1)
A7 PQQW15571Y LEAFLET, QUICK GUIDE (for
English)
A8 PQQW15572Y LEAFLET, QUICK GUIDE (for
Spanish)
P1 PQPP10152Z PROTECTION COVER (for Base
Unit)
P2 PQPH10094Z PROTECTION COVER (for Hand-
set)
P3 XZB13X19C03 PROTECTION COVER (for Charger
Unit)
P4 PQPK15669Z GIFT BOX
P5 PQXDDS400-8 MAGNET ELECTRIC TRANSDUCER,
SECURITY TAG
Ref.
No.
Part No. Part Name & Description Remarks
A101 PQLV207V AC ADAPTOR (for Base Unit)
A102 PQLV209V AC ADAPTOR (for Charger Unit)
A103 PQJA10075Z CORD, TELEPHONE
A104 PQKE10456Z2 HANGER, BELT CLIP PC+ABS-
HB
A105 PQKL10088Z1 STAND, WALL MOUNT ABS-HB
A106 PQQX15791Y INSTRUCTION BOOK (for
English) (*1)
A107 PQQW15571Y LEAFLET, QUICK GUIDE (for
English)
A108 PQQW15572Y LEAFLET, QUICK GUIDE (for
Spanish)
P101 PQPP10152Z PROTECTION COVER (for Base
Unit)
P102 PQPH10094Z PROTECTION COVER (for Hand-
set)
P103 XZB13X19C03 PROTECTION COVER (for Charger
Unit)
P104 PQPD10897Z CUSHION
Ref.
No.
Part No. Part Name & Description Remarks
