Preparation
For assistance, please visit http://www.panasonic.com/consumersupport 11
Connections
Note:
L Use only the included Panasonic AC adaptor PQLV1.
L The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel
warm during use.)
L The AC adaptor should be connected to a vertically oriented or floor-mounted AC outlet.
Do not connect the AC adaptor to a ceiling-mounted AC outlet, as the weight of the
adaptor may cause it to become disconnected.
L The unit will not work during a power failure. We recommend connecting a standard
telephone to the same telephone line or to the same telephone jack using the Panasonic
KX-J66 T-adaptor. Emergency power can be supplied to the unit by connecting a
Panasonic battery back-up power supply noted on page 6.
Fasten the AC adaptor cord.
Hook
AC adaptor
Raise the antennas.
Telephone line cord
To single-line telephone jack (RJ11C)
To power outlet (120 V AC, 60 Hz)
