Panasonic Lumix DMC-F1 - Page 7

Preparation
7
[Left View]
26 A/V OUT Socket (P76)
27 USB Socket (5pin) (P77)
28 Terminal Door
[Right View]
29 DC IN Socket (P14)
30 Memory Card/Battery Door
(P12, P15)
31 DC IN Terminal Door (P14)
[Bottom View]
32 Tripod Receptacle
[Battery Charger/AC Adaptor]
1 AC Input Terminal
2 [POWER] Indicator
3 [CHARGE] Indicator
4 Battery Attachment Section
5 DC Output Terminal
A/V OUT
USB
26
27
28
DC IN
29
30
31
32
1
5
4
2
3
